Eight in, eight out, every route independent. This is the size of matrix that runs a venue rather than a room: a bar with screens in four zones, a training suite, a command centre, a showroom where each display tells a different part of the story and the whole layout changes for an event.

Every path carries 4K60 at 18Gbps with 4:4:4 colour, and each output scales on its own — so an older 1080p screen somewhere on the estate is a local problem rather than a ceiling on the entire system. Fast switching keeps transitions tight, and audio de-embedding per output gives each zone its own feed for local amplification.

With sixty-four possible routes, control is not a nice-to-have. Front panel buttons, IR, RS-232 and TCP/IP with a built-in web GUI all address the matrix directly, so it drops into an existing control system or runs standalone from a browser. EDID management keeps the sources presenting a consistent profile regardless of what is plugged in where.

Feeding an LED video wall?

This unit is the front end of a much bigger picture. Every LED wall we ship needs a clean, stable source path in front of the receiving cards — and the cost of the electronics is a rounding error next to the screen itself. If you are specifying signal gear because a wall is coming, talk to us before you buy the boxes: we will size the whole chain and quote the display with it. See our fixed-installation LED video walls and rental LED panels.
